| Silver | Copper | Bronze | Red | |
|---|---|---|---|---|
| Type | Linear | Linear | Tactile | Clicky |
| Operating Force | 37±10 gf | 38±10 gf | 38±10 gf | 48±10 gf |
| Pre-travel | 1.8±0.5 mm | 1.1 0.3/-0.2 mm | 1.1 0.3/-0.2 mm | 1.1 0.3/-0.2 mm |
| Return Force | ≥12 gf | ≥12 gf | ≥12 gf | ≥12 gf |
| Tactile Force | N/A | N/A | 50±10 gf | 50±10 gf |
| Total Travel | 4.0±0.4 mm | 3.5±0.4 mm | 3.5±0.4 mm | 3.5±0.4 mm |
| Pre-lubed | Yes | Yes | Yes | No |
Specifications:
- MX Structured
- Factory Pre-lubed
- SMD-LED Supported
- Pins: 3-Pin Switch
- Operation Life: Up to 70M Cycles
- Stem Material: POM, MX stem
- Upper Housing: Polycarbonate
- Housing Base: Nylon PA66
- Spring: Stainless Steel Spring
Packaging Details:
All switches will be carefully packaged in plastic containers.
